SDEC 25K Series | Diesel Generator Set (60hz)
SDEC DXK diesel generator set is the complete generator set manufactured by SDEC in Shanghai. SDEC DXK diesel generator set powered by SDEC 25K series diesel engine, comes with 40-degree radiator, Match with Shangchai, Stamford, Marathon and Leroy Somer alternators for customers to choose, controlled by Deepsea, SmartGen, Comap intelligent generator set controller.
The prime power range for 60 Hz of SDEC 25K Series diesel generator set (1800 RPM) form is 450 – 660 kW.
Sinogen Series diesel generator set supports low noise generator set and chassis fuel tank, each diesel generator set system is integrated and operated independently. It can generate power with multiple generator sets in parallel, and adopts a large oil passage body and a large flow oil pump to increase the oil circulation and avoid local high temperature; SinoGen can match you with a reasonable unit configuration according to your use environment and method to ensure that it can meet you.
Prime power(kW): | 450 - 660 kW | |
---|---|---|
Engine | Type: | 6 Cylinders / In-Line |
Displacement(L): | 25.2 | |
Rate power(kW) / 1800rpm: | 572 - 800 | |
Speed regulation mode: | Electronic Governing / High-voltage common rail | |
Emission standards: | STAGE III | |
Dynamo Brand: | Evotec |
Generator Model | Prime Power (kW) | Generator Model | Standby Power (kW) | |
---|---|---|---|---|
SDLO450PEOB | 450 | SDLO560PEOB-II | 560 | |
SDLO500PEOB | 500 | SDLO600PEOB | 600 | |
SDLO560PEOB-I | 560 | SDLO660PEOB | 660 |
SDEC 25K Series Generator Set(60hz)
This is the list of all of SDEC 25K Series Diesel Generator Set.
Click here to find SDEC PowerGen by power range.
SDLO660PEOB | Diesel Genset
Prime Power: 660 kW
Standby Power: 720 kW
Engine Model: 6KTAA25-G31.1
Dynamotor: TCU368F
SDLO600PEOB | Diesel Genset
Prime Power: 600 kW
Standby Power: 660 kW
Engine Model: 6KTAA25-G32.1
Dynamotor: TCU368D
SDLO560PEOB-II | Diesel Genset
Prime Power: 560 kW
Standby Power: 600 kW
Engine Model: 6KTAA25-G38
Dynamotor: TCU368C
SDLO560PEOB-I | Diesel Genset
Prime Power: 560 kW
Standby Power: 600 kW
Engine Model: 6KTAA25-G39
Dynamotor: TCU368C
SDLO500PEOB | Diesel Genset
Prime Power: 500 kW
Standby Power: 550 kW
Engine Model: 6KTAA25-G310
Dynamotor: TCU368B
SDLO450PEOB | Diesel Genset
Prime Power: 450 kW
Standby Power: 500 kW
Engine Model: 6KTAA25-G311
Dynamotor: TCU378E
