SDEC E Series | Marine Generator Set (60hz)
Sinogen Series marine generator set is the complete generator set manufactured by Sinogen. Sinogen Series generator set powered by SDEC E series marine engine, comes with 50-degree radiator, Match with Evotec, Stamford, Marathon and Leroy Somer alternators for customers to choose, controlled by Deepsea, SmartGen, Comap intelligent generator set controller.
The prime power range for 60 Hz of Sinogen Series diesel generator set (1800 RPM) form is 260 – 320 kW.
Sinogen Series marine generator set supports low noise generator set and chassis fuel tank, each diesel generator set system is integrated and operated independently. It can generate power with multiple generator sets in parallel, and adopts a large oil passage body and a large flow oil pump to increase the oil circulation and avoid local high temperature; SinoGen can match you with a reasonable unit configuration according to your use environment and method to ensure that it can meet you.
| Prime power(kW): | 260 - 320 | ||
|---|---|---|---|
| Engine | Type: | 6 Cylinders / In-Line | |
| Displacement(L): | 11.8 - 12.8 | ||
| Rate power(kW) / 1500rpm: | 288 - 361 | ||
| Turbocharged air intake: | TA | ||
| Fuel Control System: | Mechanical/ECU+CR | ||
| Weight(kg): | N/A | ||
| Output Interface | N/A | ||
| Generator Model | Prime Power (kW) | Generator Model | Standby Power (kW) | |
|---|---|---|---|---|
| SDMO260PEOB | 260 | SDMO270PEOB | 270 | |
| SDMO320PEOB | 320 |
SDEC E Series Marine Generator Set (60Hz)
This is the list of all of SDEC E Series Marine Generator Set (60Hz).
Click here to find SDEC Generator Set by power range.
SDMO320PEOB | Marine Genset
Primer Power: 320 kW
Engine Model: SC13E500.18CA2
Rated Power: 361 kW
Alternator Model: TCM318B
SDMO270PEOB | Marine Genset
Primer Power: 270 kW
Engine Model: SC12E420.18CA1
Rated Power: 308 kW
Alternator Model: TCM288K
SDMO260PEOB | Marine Genset
Primer Power: 260 kW
Engine Model: SC12E400.18CA1
Rated Power: 288 kW
Alternator Model: TCM288J
