SDEC H Series | Marine Generator Set (50hz)
Sinogen Series marine generator set is the complete generator set manufactured by Sinogen. Sinogen Series generator set powered by SDEC H series marine engine, comes with 40-degree radiator, Match with Evotec, Stamford, Marathon and Leroy Somer alternators for customers to choose, controlled by Deepsea 6120, SmartGen, Comap intelligent generator set controller.
The prime power range for 50 Hz of Sinogen Series diesel generator set (1500 RPM) form is 50 – 107 kW.
Sinogen Series marine generator set supports low noise generator set and chassis fuel tank, each diesel generator set system is integrated and operated independently. It can generate power with multiple generator sets in parallel, and adopts a large oil passage body and a large flow oil pump to increase the oil circulation and avoid local high temperature; SinoGen can match you with a reasonable unit configuration according to your use environment and method to ensure that it can meet you.
| Prime power(kW): | 50 - 107 | ||
|---|---|---|---|
| Engine | Type: | 4 Cylinders / 6 Cylinders | |
| Displacement(L): | 4.3 - 6.5 | ||
| Rate power(kW) / 1500rpm: | 63 - 125 | ||
| Turbocharged air intake: | T/TA | ||
| Fuel Control System: | Mechanical | ||
| Weight(kg): | 495 / 675 | ||
| Output Interface | SAE 1#/14' or SAE 3#/11.5' | ||
| Generator Model | Prime Power (kW) | Generator Model | Prime Power (kW) | |
|---|---|---|---|---|
| SDMO50PEOA | 50 | SDMO64PEOA | 64 | |
| SDMO72PEOA | 72 | SDMO96PEOA | 96 | |
| SDMO107PEOA | 107 |
SDEC H Series Generator Set (50Hz)
This is the list of all of SDEC H Series Marine Generator Set (50Hz).
Click here to find SDEC Generator Set by power range.
SDMO107PEOA | Marine Genset
Primer Power: 107 kW
Engine Model: SC7H195CA2
Rated Power: 125 kW
Alternator Model: TCM228N
SDMO96PEOA | Marine Genset
Primer Power: 96 kW
Engine Model: SC7H175CA2
Rated Power: 112 kW
Alternator Model: TCM228L
SDMO72PEOA | Marine Genset
Primer Power: 72 kW
Engine Model: SC4H140CA2
Rated Power: 90 kW
Alternator Model: TCM228H
SDMO64PEOA | Marine Genset
Primer Power: 64 kW
Engine Model: SC4H125CA2
Rated Power: 80 kW
Alternator Model: TCM228G
SDMO50PEOA | Marine Genset
Primer Power: 50 kW
Engine Model: SC4H100CA
Rated Power: 63 kW
Alternator Model: TCM2280
