SDEC K Series | Marine Generator Set (50hz)
Sinogen Series marine generator set is the complete generator set manufactured by Sinogen. Sinogen Series generator set powered by SDEC K series marine engine, comes with 40-degree radiator, Match with Evotec, Stamford, Marathon and Leroy Somer alternators for customers to choose, controlled by Deepsea 6120, SmartGen, Comap intelligent generator set controller.
The prime power range for 50 Hz of Sinogen Series diesel generator set (1500 RPM) form is 400 – 519 kW.
Sinogen Series marine generator set supports low noise generator set and chassis fuel tank, each diesel generator set system is integrated and operated independently. It can generate power with multiple generator sets in parallel, and adopts a large oil passage body and a large flow oil pump to increase the oil circulation and avoid local high temperature; SinoGen can match you with a reasonable unit configuration according to your use environment and method to ensure that it can meet you.
| Prime power(kW): | 400 - 519 | ||
|---|---|---|---|
| Engine | Type: | 6 Cylinders / In-Line | |
| Displacement(L): | 25.2 | ||
| Rate power(kW) / 1500rpm: | 447 - 576 | ||
| Turbocharged air intake: | TA | ||
| Fuel Control System: | EUP | ||
| Weight(kg): | N/A | ||
| Output Interface | N/A | ||
| Generator Model | Prime Power (kW) | Generator Model | Prime Power (kW) | |
|---|---|---|---|---|
| SDMO519PEOA | 519 | SDMO432PEOA | 432 | |
| SDMO491PEOA | 491 | SDMO400PEOA | 400 |
SDEC K Series Marine Generator Set (50Hz)
This is the list of all of SDEC K Series Marine Generator Set (50Hz).
Click here to find SDEC Generator Set by power range.
SDMO400PEOA | Marine Genset
Primer Power: 400 kW
Engine Model: SC25K620.15CA1
Rated Power: 447 kW
Alternator Model: TCM3688
SDMO432PEOA | Marine Genset
Primer Power: 432 kW
Engine Model: SC25K665.15CA1
Rated Power: 480 kW
Alternator Model: TCM368D
SDMO491PEOA | Marine Genset
Primer Power: 491 kW
Engine Model: SC25K760.15CA1
Rated Power: 545 kW
Alternator Model: TCM368E
SDMO519PEOA | Marine Genset
Primer Power: 519 kW
Engine Model: SC25K800.15CA1
Rated Power: 576 kW
Alternator Model: TCM368F
